Technical Parameters
- Measuring Mode: Kinetics, End point, Fixed time, Differential, Absorbance
- Multi-standard
- Light source: 6V/10W Halogen Lamp, Life Span > 3000 hours
- Standard filter: 340nm, 405nm, 505nm, 546nm, 578nm, 620nm, 670nm and one free position
- Band width: ≤8nm
- Linearity range: 0.000–3.000 Abs
- Aspiration volume: 200–1400μl
- Flow cell: 32μl, Optical diameter: 1cm
- Cross contamination rate: ≤1%
- Temperature control: 25°C, 30°C, 37°C ±0.1°C, controlled by Peltier
- Language: English or any language on request
- Output: Built-in printer, RS232 for additional PC
- Display: 240×128 LCD
- Power supply: AC 220V ±10%, 50/60Hz
- Dimension: 430(L)mm × 320(W)mm × 220(H)mm
- Net weight: 9.0 kg
Specification
- Streamlined design, attractive appearance
- Self-calibration and trouble alarm function
- Absolutely open system: supports both programming and reagent configuration
- Warning tone for completed aspiration and other functions
- Main menu includes function sketches; software is simple, user-friendly, and fast
- Real-time curve monitoring enhances result reliability
- Memory for 100 programs and 20,000 test results; results trackable by date
- On-board quality control with results viewable in memory or on display
