The fully electric stacker is designed to allow maximum usage with minimal effort.
- It speeds up your operations and helps saves time and it also helps out reduce injury claims.
- Adjustable forks: 320mm – 685mm.
- Lowering speed: 150mm / 128mm.
- Heavy-duty steel construction.
- Motor travelling: 1200W / 24V.
- Motor lifting: 3000W / 24V.
- Front roller tandem: 78mm x 70mm.
- Rear roller: 150mm x 50mm.
- Drive wheel: 250mm x 80mm.
- Travel speed: laden/unladen: 5.2Km/h / 6.8Km/h.
- Lifting speed: laden/unladen:127mm / 170mm.
- Load centre: 600mm.
- Battery charger: 30A / 24V.
- Traction battery: 240Ah / 24V.
- Robust steel construction with a yellow and black powder coated finish.
Products specifications
| Colour | Yellow |
| Material | Steel |
| Product Weight | 1000kg |
| External Dimensions | 1770 (L) x 800 (W) x 3300 (H)mm |
| Maximum Carrying Load | 3300kg |
| Maximum Lift Height | 3300mm |
| Maximum Lifting Load | 1500kg |
| Material Details | Steel |
| Wheels | 70mm (W) x 80 (?)mm Single Nylon Wheels |
| Lowered Height | 90mm |
| Drive Motor | DC 2.2kW |
| Load Centre | 600mm |
| Minimum Turning Radius | 2065mm |
| Mechanism | Full Electric |
| Product Source | China |
| Whats in the box | 1 x Pallet Stacker Electric |
| Warranty | One-year limited product warranty |
